- Power supply type
- classic
- IP rating
- IP65
- Housing material
- metal
- Rated current
- 22 A [12V]
- Rated power
- 264W
- Efficiency
- 91%
- Inrush current
- 70 A (cold start)
- Dimensions (L x W x H)
- 252 x 90 x 43.8 mm
- Operating temperature
- -40°C ÷ +90°C
- Storage temperature
- -40°C ÷ +80°C
- Protection
- Overload | Overvoltage | Short-circuit | Over temperature
- PFC filter
- YES
- Compliance with the LVD 2014/35/EU
- EN 61347-1:2015-09/A1:2021-06, EN 61347-2-13:2015-04/A1:2017-07
- Compliance with the EMC 2014/30/EU
- EN IEC 55015:2019-11/A11:2020-07, EN IEC 61000-3-2:2019-04/A1:2021-08, EN 61000-3-3:2013-10/A1:2019-10, EN IEC 61547:2023
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- AC cable length
- 300 mm
- DC cable length
- 300 mm
- Quantity per box
- 8 pcs
- Warranty
- 7 years
- Series
- HLG
- Usage environment
- Indoor / Outdoor
