- Power supply type
- classic
- IP rating
- IP67
- Housing material
- plastic
- Rated current
- 3 A [12V]
- Rated power
- 36W
- Efficiency
- 84%
- Inrush current
- 55 A (cold start)
- Dimensions (L x W x H)
- 148 x 40 x 30 mm
- Operating temperature
- -30°C ÷ +65°C
- Storage temperature
- -40°C ÷ +80°C
- Protection
- Overload | Overvoltage
- PFC filter
- NO
- Compliance with the LVD 2014/35/EU
- EN 62368-1:2014+A11:2017
- Compliance with the EMC 2014/30/EU
- EN 55032:2015+A1:2020, EN IEC 61000-3-2:2019, EN 61000-3-3:2013+A1:2019
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- AC cable length
- 600 mm
- DC cable length
- 600 mm
- Quantity per box
- 40 pcs
- Warranty
- 3 years
- Series
- LPV/LPH
- Usage environment
- Indoor / Outdoor
