- Power supply type
- slim
- IP rating
- IP67
- Housing material
- metal
- Rated current
- 2.5 A [12V]
- Rated power
- 30W
- Efficiency
- 84%
- Inrush current
- ≤ 46 A @ 230V AC
- Dimensions (L x W x H)
- 239 x 35 x 20 mm
- Operating temperature
- -25°C ÷ +50°C
- Storage temperature
- -35°C ÷ +65°C
- Protection
- Overload | Overvoltage | Short-circuit | Over temperature
- PFC filter
- YES
- Compliance with the LVD 2014/35/EU
- EN 61347-1:2015-09, EN 61347-2-13:2015-04
- Compliance with the EMC 2014/30/EU
- EN 61000-3-3:2013-10/A1:2019-10, EN IEC 61000-3-2:2019-04, EN 61547:2009, EN 55015:2013+A1
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- AC cable length
- 170 mm
- DC cable length
- 170 mm
- Quantity per box
- 50 pcs
- Warranty
- 5 years
- Series
- RMS
- Usage environment
- Indoor / Outdoor
