- Power supply type
- furniture
- IP rating
- IP20
- Housing material
- plastic
- Rated current
- 1 A [12V]
- Rated power
- 12W
- Efficiency
- 83%
- Inrush current
- ≤ 60 A @ 230V AC / 50Hz / cold start
- Dimensions (L x W x H)
- 101 x 39.5 x 19.5 mm
- Operating temperature
- -20°C ÷ +45°C
- Storage temperature
- -35°C ÷ +65°C
- Protection
- Overload | Overvoltage | Short-circuit
- PFC filter
- YES
- Compliance with the LVD 2014/35/EU
- EN 61347-1:2015-09, EN 61347-2-13:2015-04, EN 62493:2015-11
- Compliance with the EMC 2014/30/EU
- EN IEC 61000-3-2:2019-04/A1:2021-08, EN IEC 55015:2019-11, EN IEC 55015:2019-11
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- Max cable length
- 2 m (not included with power supply)
- Quantity per box
- 200 pcs
- Warranty
- 5 years
- Series
- RAN
- Usage environment
- Indoor
