- Power supply type
- classic
- IP rating
- IP67
- Housing material
- plastic
- Rated current
- 5 A [12V]
- Rated power
- 60W
- Efficiency
- 87%
- Inrush current
- ≤ 36 A
- Dimensions (L x W x H)
- 155.5 x 41.5 x 30 mm
- Operating temperature
- -20°C ÷ +45°C
- Storage temperature
- -40°C ÷ +80°C
- Protection
- Overvoltage | Short-circuit
- PFC filter
- YES
- Compliance with the LVD 2014/35/EU
- EN 61347-1:2015-09/A1:2021-06, EN 61347-2-13:2015-04/A1:2017-07, EN 62493:2015-11/A1:2023-03
- Compliance with the EMC 2014/30/EU
- EN IEC 61000-3-2:2019-04/A1:2021-08, EN IEC 55015:2019-11/A11:2020-07
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- AC cable length
- 343 mm
- DC cable length
- 343 mm
- Quantity per box
- 25 pcs
- Warranty
- 5 years
- Series
- EVO
- Usage environment
- Indoor / Outdoor
