- Power supply type
- desktop
- IP rating
- IP20
- Housing material
- plastic
- Rated current
- 3 A [12V]
- Rated power
- 36W
- Efficiency
- 76%
- Inrush current
- ≤ 20 A (peak current, cold start)
- Dimensions (L x W x H)
- 113.6 × 49.6 × 30.5 mm
- Operating temperature
- 0°C ÷ 40°C
- Storage temperature
- -20°C ÷ +85°C
- Protection
- Overload | Overvoltage | Short-circuit
- PFC filter
- NO
- Compliance with the LVD 2014/35/EU
- EN IEC 62368-1:2020-11
- Compliance with the EMC 2014/30/EU
- EN 61000-3-3:2013-10/A1:2019-10, EN IEC 61000-3-2:2019-04, EN 55032:2015-09/A11:2020-07, EN 55035:2017-09
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- AC cable length
- H05VV-F, 1.5 m
- AC plug type
- Type E
- DC cable length
- 20 AWG, 1.2 m
- DC plug type
- 5.5 x 2.1
- Warranty
- 3 years
- Series
- EZN
- Usage environment
- Indoor
