| Chain: | 50 pcs |
| Bag: | 300 pcs |
| Small box: | 2100 pcs |
| Big box: | 4200 pcs |
- Type
- module
- Nominal power usage per module
- 0.36W [RD, GR] / 0.48W [WW, NW, PW, WH]
- Beam angle
- 160°
- Current stabilization
- YES
- Dimmable
- YES
- Module dimensions (L x W x H)
- 28 x 16 x 5.8 mm
- Maximum spacing (CC distance)
- 138 mm
- Cable length
- 110 mm
- No. of modules per chain
- 50 pcs
- Colour rendering index
- ≥82
- IP rating
- IP67
- Lifespan
- ~50000 hours
- Operating temperature
- -40°C ÷ +60°C
- Storage temperature
- -40°C ÷ +65°C
- Compliance with standards
- CE / UKCA / RoHs / WEEE / UL
- Warranty
- 5 years
- Application depth (range)
- 5-10 cm
- Category
- Backlighting
- Series
- Opticor
- Usage environment
- Indoor / Outdoor
- Application type
- channel letters
light boxes - Advertisement depth
- from 5 cm
up to 10 cm
