- Type
- set
- Function
- RGB
- IP rating
- IP20
- Output current / channel
- 6 A
- Max output current
- 10 A
- Working voltage
- 12~24V DC
- Output voltage
- 12~24V DC
- Remote controller voltage
- 3V (2×AAA)
- Output power
- 120W@12V, 240W@24V
- Stand by power consumption
- 20μA
- Controller dimension
- 85 x 45 x 22.5 mm
- Remote dimension
- 110 x 53 x 20.5 mm
- Control method
- remote control
- Number of zones
- 1
- Control distance
- ~30 m
- Transmission frequency
- 2.4 GHz RF
- Modulation method
- GFSK
- Transmitting power
- 6dBm
- Operating temperature
- -10°C ÷ +40°C
- Warranty
- 5 years
- Maximum load
- 10 A
