- Power supply type
- mesh
- IP rating
- IP20
- Housing material
- metal
- Rated current
- 6 A [12V]
- Rated power
- 72W
- Efficiency
- 89%
- Inrush current
- 50 A (cold start)
- Dimensions (L x W x H)
- 99 x 97 x 30 mm
- Operating temperature
- -30°C ÷ +70°C
- Storage temperature
- -40°C ÷ +80°C
- Protection
- Overload | Overvoltage
- PFC filter
- NO
- Compliance with the LVD 2014/35/EU
- EN IEC 61558-1:2019, EN 61558-2-16:2009+A1, EN 62368-1:2014+A11, EN 60335-1:2012+A11+A13+A1+A14+A2+A15/ EN 62233:2008
- Compliance with the EMC 2014/30/EU
- n/a
- Compliance with the RoHS 3 2015/863
- EN IEC 63000:2019-01
- Quantity per box
- 45 pcs
- Warranty
- 3 years
- Series
- LRS
- Usage environment
- Indoor
